Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine

  • Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine
  • Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine
  • Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine
Place of Origin CN
Brand Name MENSION
Certification CE RoHS
Model Number P32
Minimum Order Quantity 1 Set
Price Contact Us
Packaging Details One Plywood For One Set
Delivery Time 2 - 7 Working Days
Payment Terms T/T, Western Union, MoneyGram, Paypal
Supply Ability 1000 Sets Per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Pressing Range 6 - 51mm Hose Type Rubber Hose
Die Standard Finn Power P32 Color Blue
Customized Dies Available Crimping Force 650T
Product Name P32 Hose Press Machine Application Repair Hose Workshop
System Pressure 31.5Mpa Oil Tank 50L
Size 650*550*1360mm Weight 310Kg
Highlight

50L Hose press Machine

,

Rubber P32 Hose press Machine

,

Vertical Rubber Pipe Pressing Machine
Leave a Message
Product Description



P32 HYDRAULIC CRIMPING MACHINE FOR RUBBER

DESCRIPTION



P32 pipe press machine is most popular for its wide crimping ability for hydraulic hose, industrial hose, etc. It is convenient in operating, even new user can handle this machine without question.



Hose crimper P32 is the ideal choice for hydraulic hose assmebly making. The dies are with eight pieces, human design. The crimping surface is smooth and prevent oil leakage during hose service life.



ADVANTAGES



1. High pressure for spiraled hose crimps.
2. Adjustable for changing of die sets.
3. User-friendly design.
4. Verticle movement for master die, high accuracy.



TECHNICAL DATA



 Model

 P32 Pipe Pressing Machine

 Crimping Range

 14 - 87 (mm)

 Crimping Force

 650 (T)

 Hose Size

 1/4 - 2.5 (inch)

 Max. Opening

 31 (mm)

 Die Sets

 13

 Die Set Type

 P32

 System Pressure

 31.5 (Mpa)

 Accuracy

 0.01 (mm)

 Control

 MS

 Standard Voltage

 220 (V)

 Motor Power

 3 (KW)

 Length

 650 (mm)

 Width

 550 (mm)

 Height

 1360 (mm)

 Weight

 310 (KG)



Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine 0



P32 HOSE CRIMPER DIE SETS



Die No.

Crimping Range

 Length

6 *

6 ... 8mm

 55mm

8 *

8 ... 10mm

 55mm

10 *

10 ... 12mm

 55mm

12 *

12 ... 14mm

 55mm

14

14 ... 16mm

 55mm

16

16 ... 19mm

 55mm

19

19 ... 22mm

 55mm

22

22 ... 26mm

 70mm

26

26 ... 30mm

 70mm

30

30 ... 34mm

 70mm

34

34 ... 39mm

 75mm

39

39 ... 45mm

 75mm

45

45 ... 51mm

 90mm

51

51 ... 57mm

 90mm

57

57 ... 63mm

 100mm

63

63 ... 69mm

 110mm

69

69 ... 74mm

 110mm
74 * 74 ... 78mm 110mm
78 * 78 ... 87mm 110mm



NOTE



• " * " for non standard die sets

• Customized die sets are available

• Special voltage 110V, 208V, 240V, 415V are availbale



OPTIONAL



• UC control system

• Position limit device



Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine 1



CRIMPING APPLICATIONS FOR THE P32 HYDRAULIC HOSE CRIMPING MACHINE



Rubber Hose Pressing Machine Factory 2 Inch Hydraulic Hose Crimping Machine 2
